Wonder Mill & Wonder Miller

Wonder Mill & Wonder Miller

150000.00 - 350000.00 INR

Product Details:

  • Material Stainless Steel
  • Supply Ability : 10-20 Piece Per Day
  • Click to view more
X

Price And Quantity

  • 1 Piece
  • 150000.00 - 350000.00 INR

Product Specifications

  • Stainless Steel

Trade Information

  • 10-20 Piece Per Day
  • 3-4 Week

Product Description

Wonder Mill

We are counted amongst the foremost manufacturers and exporters of a broad range of Wonder Mill. Offered mill finds its main application for grinding various kinds of grains, crops, chilli, pulse grams, etc. Under the supervision of our adept professionals, this mill is manufactured with high precision using quality metal alloy with the aid of latest technology in line with predefined industry norms. Also, this Wonder Mill is fixed with level Sensor for input control.

Features:

  • Wonder mill is World's first fully automated touch screen integrated flour mill

  • 7" touch screen panel

  • Provides standard 128KB battery backup memory for Alarm

  • Automated controls for the individual mill and can control all the mills with a single source

  • VFD controlled Screw feeder for auto input control

  • Level Sensor for input control

  • Auto engage and auto disengage hydraulic pressing system

  • Power saving control parameters

  • Grinding Input/output Recipe for individual mill or batch

  • Auto input control

  • Auto Temperature Control

  • Auto Pressure Control

  • Auto Power Control

  • Data Recording Using- Mill Running hours, Power Consumption, Output Temperature

  • Ethernet Port optional

  • Three step control-warning, Alarm, Shut down



Particulars

Data

Base Plate Thickness

12 MM

Extra Heavy Duty 91mm hollow section Structure

91 MM x 91 MM

Shaft -EN-8, Hardened Edge with Steel Ball for Longer Life.

60 MM

Upper Bearing Housing- Heavy Duty, Having SKF Bearing

No. 6312.

Lower Bearing Housing - Heavy Duty, Having SKF Bearing Hardened Edge to work of Thrust Bearing between Shaft, Steel Ball and Lower Bearing Housing.

No. 6209

Heavy duty Spiral Bevel Gear Suitable for above mill 90 degree input 25 HP 960 RPM 1:2.2 ratio., hollow output. Complete with Coupling and Main Shaft

Spiral Bevel Gear

Required H.P.

25 H.P.
